Features:

High efficiency Class D multi-room amplifier with smart phone/tablet control
Provides a whole house audio control system with expandability to up to 18 zones (limited to six sources)
Free iOS/Android App to help control each zone/room via smartphone or tablet
Each zone can drive a single 4-ohm pair (80W x 2) of speakers or two pair of 8-ohm (40W x 2)
Includes stereo/bridge mono output for combining zones (120W @ 8 ohms)
Includes three stereo line-level pre-amp L&R RCA outputs (zones 1-3) and six stereo line-level L&R RCA analog source inputs
Zones 1-3: both the internal output and preamp outputs are active at the same time
4 Stereo line-level L&R RCA analog source inputs, one 3.5mm, and an optical/3.5mm combination source inputs
RS232 allows transferring and receiving serial data of home automation devices
Six individual zone status (3.5mm) to control external zone devices via 12V triggers
Six IR emitters (3.5mm) mono RCA outputs and one IR emitter/blaster (3.5mm mono all output)
One PA input jack to set all zones to source 1 (12Vdc trigger)
Automatic gain control brings low input levels up to a preset-level
Multi voltage selector (115V or 230V)
AC input connection with fuse receptable (CE certified)
Optional control keypads feature built-in IR receivers for each zone
IR remote included in the optional control keypad kit along with Cat5e network cable hub
Includes expansion ribbon cable, pre-installed rack ears, and speaker terminal blocks

The NERO MAX12 is a highly efficient Class D multi-channel audio distribution system that powers up to six zones with up to six different sources for well-rounded and easy to manage residential and commercial audio systems. This multi-functional and highly compatible and expandable amplifier is engineered with cutting-edge features including full control for iOS and Android devices. The free App duplicates the optional control keypads and allows you to select zones, adjust volume, treble and bass, or turn all zones on or off directly through a smartphone or tablet. Designed with A/V integrators and homeowners who want the most flexibility, the NERO MAX12 includes numerous input sources including four stereo line-level RCA, one 3.5mm aux, and one optical/3.5mm combo analog source input. In addition, RS232 and ethernet ports allow transferring and receiving the serial data between home automation systems. The NERO MAX12 features six zones of reliable amplification at 40W per zone at 8ohms or 80W x 2 @ 4 ohms and includes stereo/bridge mono output for combining zones (120W @ 8 ohms).

Expanding Beyond Six Zones

The NERO MAX12 includes unbalanced line level pre-amp outputs that can be used to connect an additional amplifier for Zones 1-3, a powered subwoofer, or dedicated subwoofer amplifier with a passive in-wall sub. The system can be expanded by adding 1 to 2 more multi-channel amplifier base control units to expand to up to 12 or 18 zones with a maximum of six sources. An expansion cable connects to the additional units and there is a “master/minion” switch on each unit where you determine which component is the master featuring the six-source inputs. The NERO Max12 can be controlled via, R232, Wi-Fi/App, or optional IR remote/control keypads.
