SKU: IWS8
OSD IWS88" 150W Pro Series In-Wall Home Theater Subwoofer, Easy Install & Paintable Grille, Single
Features
- 8" Polypropylene Woofer
- Butyl Rubber Surround for High Performance
- Dog-Leg Mounting System
- Integrated Rear Dust Shield
- Spray Paintable Frame & Grill
In-wall subs are a great way to experience low frequencies effects without filling up floor space. An excellent in-wall subwoofer at an excellent price, the IWS8 is an 8" passive sub with power handling up to 150 Watts. Installation is easy with our dog-ear bracket system that mounts to the sheet-rock after the cut-out hole has been made. The grille is also paintable to match your room decor and we include a cutout template that doubles as a paint shield.
Amplifier Suggestions
OSD Audio in-wall subs are passive devices, meaning they do not include a built-in amplifier like you would find in our active "box" subs. You will have to provide additional power, specifically a subwoofer amplifier, to drive it. We recommend our SMP200 dedicated subwoofer amplifier that features 120 watts (mono) and front panel controls, phase switch, frequency control knob (35 Hz to 160 Hz) and volume control.
Warning: California's Proposition 65
Warning:
This product can expose you to chemicals, including vinyl chloride, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
- Speaker Type: 8" In-Wall Subwoofer
- Woofer: 8" Polypropylene
- Frequency Response: 40Hz - 200Hz +/-3dB
- Power Handling: 150 Watts
- Sensitivity: 2.83V/1m: 87 dB
- Impedance: 8 Ohms
- Inputs: Spring Binding Posts
- Install-friendly Dog Ear Installation Brackets
- Cut-Out Template for Easy Installation
- Paintable Grille & Frame Included
- Integrated Rear Dust Shield
- Sold As: Single
- Mounting Depth (Assuming .5" Drywall): 3.63"
- Unit Dimensions: (L x H x D) 10" x 10" x 3.6"
- Cutout Dimensions: (L x H) 8.75" x 8.75"
- Weight: 6.5 lbs
- Warranty: 10 Years
- *Note: Requires Additional Subwoofer Amplifier
View Owner's Manual
13 Questions asked
Have a Questions?
What's on your mind?
george king • 12/17/2019, 2:17:43 PM
how many of these subs can i connect on to a OSD SMP250?
Customer Service • 12/17/2019, 2:17:43 PM
Hi George:
You can connect two 8 ohm subs in Parallel or four 8 ohm subs in Series Parallel.
TL/3896
Eric • 12/17/2019, 2:17:43 PM
Does this connect to the front left and front right speaker jacks when using it as a 5.1 system?
Customer Service • 12/17/2019, 2:17:43 PM
Hi Eric:
This just a 8" In-wall Passive Subwoofer that we recommend using it with our SMP60 or SM-250 Dedicated Sub-woofer amplifiers that connect to your Sub-woofer output on your Receiver. The Sub Amplifiers allows you to adjust the output gain, Phase switch and adjustable low pass crossover point. The SMP250 has a LFE input which is the output from most Audio Video Receivers that the adjustments are controlled by the Receiver (LFE: Low Frequency Effects) The Sub output is controlled just like the other 5 or 7 channels of surround.
TL/4238
Ron L. • 12/17/2019, 2:17:43 PM
The speaker came with these foam black stickers but nowhere in the manual does it state what to do with them...
Customer Service • 12/17/2019, 2:17:43 PM
Hi Ron:
The Black strips that come with the IWS8 you insert in the groove in the frame that holds the grill to the front of the speaker. You use it to make a tight fit for the speaker grille, so it does not pop out while moving lots of air while reproducing the low frequencies.
TL/5397
